Summary
An obsolete PLC failed, and the original program could not be recovered. A new PLC and HMI were installed with new programming to restore original function.
Key Benefits
- Maintainable control system
- Improved user interface
- Fast turnaround
- 75% cost savings compared to OEM quote
Technologies used
- Allen Bradley Micro 800 PLC
- Allen Bradley PanelView 800 HMI
The Breen Machine Solution
A bag filling and sealing machine was running on obsolete hardware. When the 30-year-old PLC died, the program could not be recovered. There was minimal documentation of the system design or function. The OEM would only consider a complete control system retrofit, which wasn’t cost justified for this limited use machine, so the challenge was to select and program a new PLC and HMI, starting with almost no information, in a cost and time sensitive way.
Breen Machine worked closely with the customer to understand the function of the machine and develop a plan. New parts were selected to replace the PLC, operator interface, and a few peripheral components. Breen Machine wrote the new program while the parts were shipping so installation could happen as soon as they arrived. The install and program debug took a day and the customer was able to resume production. Breen Machine offers the personal touch and creative solutions that support small manufacturers. To quote this customer: “The [OEM] wanted $20,000 to replace it. [Breen Machine] came in for under $5,000 and got it done 3 times faster than anything they could’ve done. It was great!”
Do you have aging control systems? Let us know how we can help.
